MAGNETIC
DIMENSIONS
|
MICROMETALS
Part No.
|
AL
nH/N2
|
OD
in/mm
|
ID
in/mm
|
Ht
in/mm
|
cm
|
A
cm2
|
V
cm3
|
|
T80-8B/90
|
29.5
|
.795/20.2
|
.495/12.6
|
.375/9.53
|
5.14
|
.347
|
1.78
|
|
T80-14B
|
11.0
|
|
T80-18B
|
46.5
|
|
T80-19B
|
46.5
|
|
T80-26B
|
71.0
|
|
T80-38B
|
72.0
|
|
T80-40B
|
59.0
|
|
T80-45B
|
84.0
|
|
T80-52B
|
63.0
|
|
|
|
T80-26D
|
92.0
|
.795/20.2
|
.495/12.6
|
.500/12.7
|
5.14
|
.453
|
2.33
|
|
T80-40D
|
79.0
|
|
T80-52D
|
83.0
|
|
|
|
T90-8/90
|
30.0
|
.900/22.9
|
·550/14.0
|
.375/9.53
|
5.78
|
.395
|
2.28
|
|
T90-18
|
47.0
|
|
T90-19
|
47.0
|
|
T90-26
|
70.0
|
|
T90-38
|
73.0
|
|
T90-40
|
57.0
|
|
T90-45
|
85.0
|
|
T90-52
|
64.0
|
|
|
|
T94-2
|
8.4
|
.942/23.9
|
.560/14.2
|
.312/7.92
|
5.97
|
.362
|
2.16
|
|
T94-8/90
|
25.0
|
|
T94-14
|
10.0
|
|
T94-18
|
42.0
|
|
T94-19
|
42.0
|
|
T94-26
|
60.0
|
|
T94-38
|
65.0
|
|
T94-40
|
49.0
|
|
T94-45
|
76.0
|
|
T94-52
|
57.0
|
|
|
|
T95-26B
|
84.0
|
.942/23.9
|
.495/12.6
|
.375/9.53
|
5.72
|
.510
|
2.91
|
|
T95-52B
|
84.0
|
|
|
|
T106-2
|
13.5
|
1.060/26.9
|
.570/14.5
|
.437/11.1
|
6.49
|
.659
|
4.28
|
|
T106-8/90
|
45.0
|
|
T106-14
|
17.0
|
|
T106-18
|
70.0
|
|
T106-19
|
70.0
|
|
T106-26
|
93.0
|
|
T106-30
|
30.0
|
|
T106-34
|
40.0
|
|
T106-35
|
40.0
|
|
T106-38
|
108.0
|
|
T106-40
|
81.0
|
|
T106-45
|
125.0
|
|
T106-52
|
95.0
|
|
|
|
T106-18A
|
49.0
|
1.060/26.9
|
.570/14.5
|
.312/7.92
|
6.49
|
.461
|
3.00
|
|
T106-26A
|
67.0
|
|
T106-40A
|
58.0
|
|
T106-52A
|
67.0
|
|
|
|
T106-18B
|
91.0
|
1.060/26.9
|
.570/14.5
|
.575/14.6
|
6.49
|
.858
|
5.57
|
|
T106-19B
|
91.0
|
|
T106-26B
|
124.0
|
|
T106-40B
|
106.0
|
|
T106-52B
|
124.0
|
|
|
|
T124-26
|
58.0
|
1.245/31.6
|
.710/18.0
|
.280/7.11
|
7.75
|
.459
|
3.55
|
|
