Part No.
|
AL
nH/N2
|
A
in/mm
|
B
in/mm
|
C
in/mm
|
D
in/mm
|
G
in/mm
|
H
in/mm
|
cm
|
A
cm2
|
V
cm3
|
|
EM102-8
|
40.1
|
1.000/25.4
|
1.000/25.4
|
.500/12.7
|
.800/20.3
|
.800/20.3
|
.350/8.89
|
6.28
|
.637
|
4.00
|
|
EM102-52
|
84.8
|
|
-
|
|
EM126-8
|
48.7
|
1.250/31.8
|
1.250/31.8
|
.570/14.5
|
.916/23.3
|
1.010/25.7
|
.438/11.1
|
7.46
|
.960
|
7.43
|
|
EM126-52
|
119.0
|
|
EM126-52/G040
|
49.9
|
|
Gapped EM126 with
center gap .080 in/2.03mm per set
|
|
-
|
|
EM145-26
|
125.0
|
1.455/37.0
|
1.370/34.8
|
.425/10.8
|
.950/24.1
|
1.035/26.3
|
.425/10.8
|
8.50
|
.915
|
9.28
|
|
EM145-52
|
125.0
|
|
-
|
|
EM150-8
|
63.7
|
1.500/38.1
|
1.500/38.1
|
.750/19.1
|
1.200/30.5
|
1.190/30.2
|
.536/13.6
|
9.46
|
1.45
|
13.7
|
|
EM150-52
|
127.0
|
|
-
|
|
EM169-8
|
82.3
|
1.685/42.8
|
1.654/42.0
|
.766/19.5
|
1.204/30.6
|
1.360/34.5
|
.580/14.7
|
9.90
|
1.79
|
17.7
|
|
EM169-40/13
|
148.0
|
|
EM169-52
|
151.6
|
|
EM169-40/G052/13
|
61.3
|
|
Gapped EM169 with
center gap .104 in/2.64mm per set
|
|
-
|
|
EM193-8
|
77.0
|
1.930/49.0
|
1.930/49.0
|
.877/22.3
|
1.530/38.9
|
1.530/38.9
|
.676/17.2
|
12.1
|
2.28
|
27.5
|
|
EM193-52
|
168.0
|
|
EM193-40/G060/13
|
70.6
|
|
Gapped EM193 with
center gap .120 in/3.05mm per set
|
|
-
|
|
EM220-26*
|
230.0
|
2.210/56.1
|
2.180/55.4
|
.820/20.8
|
1.510/38.3
|
1.520/38.6
|
.780/19.8
|
13.2
|
2.90
|
45.0
|
|
EM220-40
|
196.0
|
|
EM220-26/G020
|
173.0
|
|
EM220-40/G020
|
143.0
|
|
Gapped EM220 with
center gap .040 in/1.02mm per set
|
|
-
|
|
EM221-8
|
89.9
|
2.210/56.1
|
2.200/55.9
|
1.070/27.2
|
1.760/44.7
|
1.760/44.7
|
.850/21.6
|
13.7
|
3.22
|
44.0
|
|
EM221-40/13
|
188.0
|
|
EM221-52
|
228.0
|
|
Gapped EM220 with
center gap .040 in/1.02mm per set
|
