MAGNETIC
DIMENSIONS
|
MICROMETALS
Part No.
|
AL*
nH/N2
|
A
in/mm
|
B
in/mm
|
Length
in/mm
|
D
in/mm
|
E
in/mm
|
cm
|
A
cm2
|
V
cm3
|
|
HS300-8
|
68
|
1.020/25.9
|
.650/16.5
|
.500/12.7
|
.520/13.2
|
.140/3.56
|
5.92
|
.806
|
4.61
|
|
HS300-26
|
147
|
|
HS300-52
|
147
|
|
-
|
|
HS300-8A
|
83
|
1.020/25.9
|
.650/16.5
|
.625/15.9
|
.520/13.2
|
.140/3.56
|
5.92
|
1.01
|
5.77
|
|
HS300-26A
|
179
|
|
HS300-52A
|
179
|
|
-
|
|
HS300-8B
|
95
|
1.020/25.9
|
.650/16.5
|
.750/19.1
|
.520/13.2
|
.140/3.56
|
5.92
|
1.21
|
6.92
|
|
HS300-26B
|
208
|
|
HS300-52B
|
208
|
|
-
|
|
HS300-8C
|
107
|
1.020/25.9
|
.650/16.5
|
.875/22.2
|
.520/13.2
|
.140/3.56
|
5.92
|
1.41
|
8.06
|
|
HS300-26C
|
232
|
|
HS300-52C
|
232
|
|
-
|
|
HS400-26
|
221
|
1.500/38.1
|
.960/24.4
|
.750/19.1
|
.765/19.4
|
.205/5.21
|
8.71
|
1.78
|
15.1
|
|
HS400-26A
|
286
|
1.000/25.4
|
2.37
|
20.1
|
|
HS400-26B
|
335
|
1.250/31.8
|
2.96
|
25.2
|
|
HS400-26C
|
371
|
1.500/38.1
|
3.56
|
30.2
|
|
