MAGNETIC
DIMENSIONS
|
MICROMETALS
Part No.
|
AL
nH/N2
|
A
in/mm
|
B
in/mm
|
C
in/mm
|
D
in/mm
|
F
in/mm
|
G
in/mm
|
cm
|
A
cm2
|
V
cm3
|
W
cm2
|
|
E49-66
|
32.0
|
.500/12.7
|
.437/11.1
|
.125/3.18
|
.312/7.93
|
.125/3.18
|
.375/9.53
|
2.86
|
.101
|
.288
|
.252
|
|
E49-70
|
45.0
|
|
Bobbin: PB49
Reference Size: US LAM EE-28-29
|
|
|
|
E75-60
|
50.0
|
.750/19.1
|
.635/16.1
|
.187/4.75
|
.455/11.6
|
.187/4.75
|
.562/14.3
|
4.20
|
.226
|
.936
|
.551
|
|
E75-70
|
72.0
|
|
Bobbin: PB75
Reference Size: US LAM EI-187
|
|
|
|
E100-60
|
75.0
|
1.000/25.4
|
.750/19.1
|
.250/6.35
|
.500/12.7
|
.250/6.35
|
.750/19.1
|
5.08
|
.403
|
2.05
|
.806
|
|
Bobbin: PB100E
Reference Size: US LAM EE-24-25
|
|
|
|
E137-60
|
100.0
|
1.375/34.9
|
1.145/29.1
|
.375/9.53
|
.770/19.6
|
.375/9.53
|
1.000/25.4
|
7.40
|
.907
|
6.72
|
1.55
|
|
E137-66
|
113.0
|
|
Bobbin: PB137
Reference Size: US LAM EI-375
|
|
|
|
E162-66
|
168.0
|
1.625/41.3
|
1.342/34.1
|
.500/12.7
|
.842/21.4
|
.500/12.7
|
1.125/28.6
|
8.41
|
1.61
|
13.6
|
1.70
|
|
Bobbin: PB162
Reference Size US LAM EI-21
|
|
|
|
E168-60
|
135.0
|
1.685/42.8
|
1.660/42.2
|
.590/15.0
|
1.210/30.7
|
.475/12.0
|
1.210/30.7
|
10.4
|
1.81
|
18.5
|
2.87
|
|
E168-66
|
155.0
|
|
Bobbin: PB168
Reference Size: DIN 42/15
|
|
|
|
E168-66A
|
190.0
|
1.685/42.8
|
1.660/42.2
|
.787/20.0
|
1.210/30.7
|
.475/12.0
|
1.210/30.7
|
10.4
|
2.41
|
24.6
|
2.87
|
|
Bobbin: PB168A
Reference Size: DIN 42/20
|
|
|
|
E220-60
|
196.0
|
2.210/56.1
|
2.180/55.4
|
.820/20.8
|
1.510/38.3
|
.680/17.3
|
1.520/38.6
|
13.2
|
3.62
|
47.7
|
4.09
|
|
E220-66
|
220.0
|
|
Bobbin: PB220
Reference Size: DIN 55/21
|
|
|
|
E305-60
|
222.0
|
3.051/77.5
|
3.051/77.5
|
.933/23.7
|
2.118/53.8
|
.933/23.7
|
2.118/53.8
|
18.5
|
5.62
|
104
|
8.10
|
|
E305-66
|
250.0
|
|
Bobbin PB305 or
PB305/V0
|
|
|
|
E305-60A
|
280.0
|
3.051/77.5
|
3.051/77.5
|
1.244/31.6
|
2.118/53.8
|
.933/23.7
|
2.118/53.8
|
18.5
|
7.49
|
139
|
8.10
|
|
E305-66A
|
315.0
|
|
Bobbin: PB305A or
PB305A/V0
|
|
|
|
E450-60
|
400.0
|
4.500/114
|
3.636/92.4
|
1.375/34.9
|
2.250/57.2
|
1.375/34.9
|
3.120/79.3
|
22.9
|
12.2
|
280
|
12.7
|
|
E450-66
|
460.0
|
|
Bobbin: PB450/V0
Reference Size: US LAM EI-30
|
|
|
|
E610-66
|
500.0
|
6.102/155
|
6.102/155
|
1.866/47.4
|
4.236/108
|
1.866/47.4
|
4.236/108
|
37.0
|
22.5
|
832
|
32.4
|
|
|
|
E827-60
|
460.0
|
8.268/210
|
9.843/250
|
2.520/64
|
7.323/186
|
2.520/64
|
5.748/146
|
58.2
|
41.0
|
2384
|
76.26
|
|
E827-63
|
320.0
|
|
E827-66
|
530.0
|
